Cable Trays & Trays Accessories

MAGDIEL ENGINEERING PRIVATE LIMITED is leading manufacturer, exporter & supplier of various types of cable trays & Cable trays accessories like perforated type, ladder type, angle type, FRP & Raceways trunking cable trays, Cable trays supports, coupler plates, jointing plates, covers and other cable trays accessories.

(1) Perforated Type cable Trays : Perforated cable tray with channel support offer an effective way to manage wiring while keeping it accessible, organized and secure. These systems accommodates large number of branch lines and offer high load-bearingcapacity for various industries such as Ship Building, Steel & Power Plant, Cement Plant, sugar Industries etc. Perforated cable tray are made for Easy Installations, Instant approach for repairs and replacement of cables.

(|) Light Duty Perforated Cable Tray (18 SWG)

(||) Medium Duty Perforated Cable Tray (16 SWG)

(|||) Heavy Duty Perforated Cable Tray (14 SWG)

Material Use : G.P. Sheet / HR Sheet/ CRCA Sheet/ SS Sheet

Size : Width 50mm to 1200mm, Height 25mm to 200mm, Thickness 1.2mm to 3.0mm Length 2500mm/ 3000mm

Finishing : Epoxy/Enamel Painted, Powder Coated, GP Sheet, Hot Dip Galvanized



(2) Ladder Type cable Trays : Ladder cable trays are widely used to distribute & manage high voltage electrical wiring in industries. Ladder cable tray offer high strength as per specification which made them perfect for heavy duty power distribution in industries. This array is developed from pre-galvanized sheets having high capacity, and well suited for varied applications.

Medium Duty Ladder Cable Tray (16 SWG)

Heavy Duty Ladder Cable Tray (14 to 10 SWG)

Material Use : Pre-Galvanized Sheet (G.P. Sheet)/ HR Sheet/ CRCA Sheet / SS Sheet

Size: Width 150mm to 1200mm, Height 50mm to 200mm, Thickness-1.6mm to 3.0mm Length-2500mm/ 3000mm

Finishing : Epoxy/Enamel Painted, Powder Coated, GP Sheet, Hot Dip Galvanized

(3) Angle Type cable Trays: : Angle type cable trays are used where high load capacity required. They are made up of equal/unequal Indian standard Angles (ISA). Angles are used as Runners and M.S. Flats as Rungs. Rung spacing is 250mm for 2500mm Length and 300mm for 3000mm Length of cable trays. Rungs can be provided single/double, as per the customer's choice

High Tension angle cable Tray

Material Use : M.S. Angle & M.S. Flats.

Size : Width 150mm to 1000mm, Height 30mm to 100mm ,Thickness 3.0mm to 8.0mm Length 2500mm/ 3000mm

Finishing : Epoxy/Enamel Painted, Powder Coated, Hot Dip Galvanized

(4) FRP Type cable Trays : Our FRP cable support systems are ideal for locations where the metallic systems get easily corroded (Iron forms rusty layer and Aluminum makes white or silver greyish patina).Our cable trays meet stringent Fire retardant requirements.

Our cable support systems are available in two types- Ladder cable tray and perforated cable tray. These are good replacement of those cable trays that easily get corrode, spread heat and erode.

(|) Ladder Type Tray : Width 100 mm to 1000mm, Height 80mm and 100 mm, Thick 3mm to 5mm, Length 3 MTR C-Channel 80x30mm, 100x30mm Rung pipe 25x25x9mm

(2) Perforated Type Tray : Width 80 mm and 100mm, Height 30mm, Thick 3mm to 5 mm, Length 3 MTR
(5) Raceway / Trunking cable Trays: : Cable Raceways provides perfect solutions for wiring management systems. The array increases the system performance and can be installed in various areas. The range offers corrosion free and long lasting operations.

Light Duty Flooring Race Way/Trunking (18SWG)

Medium Duty Flooring Race Way/Trunking

Heavy Duty Flooring Race Way/Trunking

Material Use : G.P. Sheet/ HR Sheet / CRCA Sheet / SS Sheet

Size : Width 100mm to 1000mm, Height 50mm to 200mm, Thickness 1.2mm to 3.0mm Length 2500mm/ 3000mm

Finishing : Epoxy/Enamel Painted, Powder Coated, Hot Dip Galvanized

Cable Tray Accessories :
(1) Cable Tray Accessories : We provide all necessary accessories for Ladder Type Cable Trays like straight ladder, horizontal elbow, horizontal tee, horizontal cross, horizontal reducer, vertical elbow up, inside, vertical elbow down, outside, coupler plate, fasteners etc.

Horizontal Elbow Bend

Horizontal Tee Bend

Horizontal Cross Bend

Horizontal Reducer Bend

Vertical Elbow UP Bend

Vertical Elbow Inside Bend

Vertical Elbow Outside Bend

Coupler Plate

Fastener

(2) Jointing Plate

Material Use : HR Sheet/ G.I

Size : Depend On Cable Tray Height But Standard Is 50 mm to 200

Finishing : Electro Plating , Hot –Dip G.I , Powder Coating, Painted.

(3) Cable Tray Cover

Material Use : HR Sheet/ G.I Sheet.

Size : Depend On Cable Tray Width

Thick : 1.2 mm to 3 mm

Length : 2500mm

Height : 20 To 30mm

(4) Slotted Angle:

Material : HR Sheet/ MS Sheet

Size : 40 x 40 x 2 mm , 35 x 35 x 2 mm

Finishing : Electro Plating G.I , Hot-Dip G.I , Powder Coating , Painted.

(5) Junction Box

Material Use : H.R Sheet/ G.I Sheet

Size : 200 x 200mm, 300 x 300mm, 400 x 400mm

Finishing : Hot-Dip G.I , Electro Plating , Powder Coating , Painted
